MSI H310M PRO-M2 (INTEL) MOTHERBOARD

MSI H310M PRO-M2 (INTEL) MOTHERBOARD SPESIFIKASI: Processor Supports 8th Gen Intel® Core™ processors, Pentium® Gold and Celeron® processors for Socket LGA1151 Chipset Intel® H310 Chipset Memory 2 x DDR4 memory slots, support up to 32GB Supports DDR4 2666/ 2400/ 2133 MHz Dual channel memory architecture Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) Slots 1 x PCIe 3.0 x16 slot 2 x PCIe 3.0 x1 slotss Onboard Graphics 1x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz1 1x DVI-D port, supports a maximum resolution of 1920x1200@60Hz* 1x HDMI™ port 1.4, supports a maximum resolution of 4096x2160@30Hz* *Supports up to 2 displays simultaneously Storage Intel® H310 Chipset 4 x SATA 6Gb/s ports 1 x M.2 slot (Key M) Support up to PCIe 2.0 x4 and SATA 6Gb/s Supports 2242/ 2260 /2280 storage devices USB Intel® H310 Chipset 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connectors) 6 x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connectors) Audio Realtek® ALC887 Codec 7.1-Channel High Definition Audio LAN 1 x Intel I219-V Gigabit LAN controller Internal connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) 1 x USB 2.0 connector (supports additional 2 USB 2.0 ports) 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 1 x Serial port connector 2 x Front panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper Back panel ports - PS/2 Combo Port - VGA Port - HDMI™ Port - USB 3.1 Gen1 - LAN Port - HD Audio Connectors - USB 2.0 Port - DVI-D Port - USB 2.0 Port Dimensions -9.1 in. x 7.3 in. (23.0 cm x 18.5 cm) -m-ATX Form Factor Mounting 6 mounting holes
