The Thermaltake View 380 XL TG ARGB Black is a panoramic, dual-chamber mid-tower chassis featuring 4mm tempered glass panels on the front and side for maximum component viewing. It supports up to ATX motherboards, 420mm GPUs, and features pre-installed 120mm ARGB Lite fans, offering massive air/liquid cooling support (up to 360mm radiator) and extensive cable management. The View 380 XL TG ARGB Mid Tower Chassis is a dual-chamber ATX case with Hidden-Connector Motherboard support, four 120mm Hydraulic Bearing ARGB Lite fans, and space for a 360mm radiator at both the top and motherboard side. It supports up to ten 120mm fans and features a built-in GPU holder, front I/O ports, a recessed bottom compartment, and an angled motherboard side design, offering users enhanced flexibility for their ideal build.
PRODUCT DETAIL
THERMALTAKE VIEW 380 XL TG ARGB BLACK GAMING CASING SPESIFIKASI PRODUCT NUMBER CA-11E-00M1WN-00 SERIES View MODEL View 380 XL TG ARGB DIMENSIONS 471 x 288 x 469 mm (18.54 x 11.34 x 18.46 inch) PANEL 4mm Tempered Glass x 2 COLOR Black MATERIAL SPCC COOLING SYSTEM Right(intake): 120 x 120 x 25 mm ARGB Lite Reverse fan (1000rpm, 21.9 dBA) x 3 Rear(exhaust): 120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 1 DRIVE BAYS 1 x 3.5”, 2 x 2.5” or 3 x 2.5” EXPANSION SLOTS 8 MOTHERBOARDS 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) I/O PORT USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1 PSU Standard PS2 PSU (optional) FAN SUPPORT Top: 3 x 120mm, 2 x 120mm, 1 x 120mm, 2 x 140mm, 1 x 140mm Right: 3 x 120mm, 2 x 120mm, 1 x 120mm Rear: 1 x 120mm Bottom: 3 x 120mm, 2 x 120mm, 1 x 120mm RADIATOR SUPPORT Top: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Right: 1 x 360mm, 1 x 240mm, 1 x 120mm Rear: 1 x 120mm CLEARANCE CPU cooler max height: 160mm VGA max length: 420mm PSU max length: 180mm
